Hotron SSS-5 Safety Sensors

Hotron SSS-5 Safety Sensors
hotron-sss-5-safety-sensors6021_large_13961.jpg - Image 1hotron-sss-5-safety-sensors6022_large_17259.jpg - Image 2hotron-sss-5-safety-sensors6023_large_17299.jpg - Image 3hotron-sss-5-safety-sensors6024_large_17299.jpg - Image 4


PRODUCT OPTIONS AVAILABLE
TYPE CODE 1+ Qty Buy
SSS-5 Safety Sensor 340mm LongHOT-SSS-5S1£132.00Buy
SSS-5 Safety Sensor 700mm LongHOT-SSS-5M1£138.00Buy
Prices are Inclusive of VAT

HOTRON SSS-5 SAFETY SENSORS DESCRIPTION

Pedestrian Safety
Six spot, 900-1,000mm wide, infrared safety curtain with 1 PCB unit
Safety beams can be focused very close to the ground for maximum safety
Externally and Internally monitored safety system
EN16005 compliant
Ease of Installation
Simple push button setting of sensor detection distance
Only one PCB units required for full safety on each side of the door
Removable terminal block simplifies wiring, and allows installers to use their own desired cable length
Large, robust, internal components aid quick installation
Performance Reliability
5-Year Warranty against manufacturing defects
Mean Time Between Failure rate of 19.7 years
Maintenance Free
Robust housing and parts prevent damage during installation and operation
Ability to deal in realtime with changing floor surfaces and floor reflection levels.

Model:
SSS-5 Safety Sensor for Swing Doors　　
Detection Method:
Static Presence Detection using PSD distance measurement
Installation height:
2600mm (8.5ft) Max
Sensor Dimensions:
SSS-5S1 = 360mm, SSS-5M1 = 692mm, SSS-5L1 = 1,023mm
Presence Timer:
Infinity
IP Rating:
54
Power Supply:
12 to 24V AC or DC ± 10%
Power Consumption:
AC12V-1.7 [VA] (Max), DC12V-95 [mA], AC24V-2.3 [VA] (Max), DC24V-55 [mA]
Operating temperature:
-20°C to +60°C, (-4°F to 140°F)
Weight:
SSS-5S1: 350[g] APPROX. SSS-5M1: 540[g] APPROX. SSS-5L1: 760[g] APPROX.
Available Colours:
Black
